ロール オーバー保護システム for BMW 8 Series G14 カブリオレ 840dX (2020)

This ロール オーバー保護システム technical drawing provides a detailed breakdown of the assembly for the 8 Series G14 カブリオレ 840dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.

ロール オーバー保護システム
No. 記述 補足 数量  から   まで  パーツ番号 価格 備考
01 グリル カバー 1 51437435092 NoS Shop at ECS Tuning
02 クロスメンバーカバー 1 51467451981 NoS Shop at ECS Tuning
03 カバー ロールオーバー バー LH 1 51467480317 NoS Shop at ECS Tuning
03 カバー ロールオーバー バー RH 1 51467480318 NoS Shop at ECS Tuning
04 カバー キャップ グリル 4 51467481629 NoS Shop at ECS Tuning
05 フィリスター ヘッド スクリュー M5X18 6 07147238657 Shop at ECS Tuning
06 リベット 14 07147401727 Shop at ECS Tuning
07 クリップ、黄 3 07146955627 $0.66 Shop at ECS Tuning
08 ストップ クッション 4 52207326087 Shop at ECS Tuning
備考
  • NoS = No Stock (部品センターに保管されていない。)
