ナビゲーション システム for BMW MINI R50 Cooper (2000)
This ナビゲーション システム technical drawing provides a detailed breakdown of the assembly for the MINI R50 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| No. | 記述 | 補足 | 数量 | から | まで | パーツ番号 | 価格 | 備考 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | 以下の装備車用 日本仕様 |
L807A=いいえ |
||||||||
| 01 | RP REMAN ナビゲーション ユニット III | 1 | 03/2003 | 65906924829 | $2560.00 | Shop at ECS Tuning | ||||
| 02 | NAVI コンピューター ホルダー | 1 | 65906916058 | $8.40 | 生産終了 | Shop at ECS Tuning | ||||
| 03 | カバー、NAVI システム本体 | 1 | 65906952084 | $41.11 | +core | Shop at ECS Tuning | ||||
| 04 | NAVI コンピューター ホルダー | 1 | 65906914396 | $15.25 | Shop at ECS Tuning | |||||
| 05 | 六角ナット ワッシャー付き | M5 | 4 | 63259128043 | $0.72 | Shop at ECS Tuning | ||||
| 06 | トルクス ボルト プラスチック用 | L=10MM | 11 | 51268354462 | $0.39 | Shop at ECS Tuning | ||||
| 07 | タッピング スクリュー | 5.5X32MM | 4 | 07119903694 | $2.05 | Shop at ECS Tuning | ||||
| 07 | タッピング スクリュー | 5.5X32MM | 4 | 07119904193 | 生産終了 | Shop at ECS Tuning | ||||
備考
- 生産終了 = このパーツの製造は終了しています。在庫のみ
- +core = コア追加料金 (取り外したパーツを返却する必要があるかもしれません)
