Brandstofpomp/brandstoffilter for BMW 1500-2000CS 2000
This Brandstofpomp/brandstoffilter technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 2000. It includes part names, part numbers and all associated mounting hardware.
| Nr. | Omschrijving | Toevoeging | Aantal | Van | Tot | Onderdeelnummer | Prijs | Notities | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Benzinetank | 55L | 1 | 16111107592 | $767.54 | Shop at ECS Tuning | ||||
| 02 | Onderzetterplaat | A6,4-200HV-ZNS3 | 5 | 07119903791 | $0.11 | Shop at ECS Tuning | ||||
| 03 | Cilinderschroef | M6X18 | 5 | 07119919781 | Vervallen | Shop at ECS Tuning | ||||
| 06 | Afdichtrubber | 1 | 16111179680 | $6.70 | Shop at ECS Tuning | |||||
| 07 | Tankafsluitdop zonder slot | 1 | 16111184718 | $11.65 | Shop at ECS Tuning | |||||
| 09 | Mof | 1 | 16114680130 | Vervallen | Shop at ECS Tuning | |||||
| 12 | Pakking | SELBSTKLEBEND | 1 | 16111117053 | $17.96 | Shop at ECS Tuning | ||||
| 13 | Brandstoffslang | 8X13MM | X | 16121180409 | $20.43 | Shop at ECS Tuning | ||||
| 14 | Afsluitschroef | M10X1 | 1 | 11122244830 | $2.12 | Shop at ECS Tuning | ||||
| 15 | Afdichtring | A10X13,5-CU | 1 | 07119963072 | $0.11 | Shop at ECS Tuning |
Notities
- Vervallen = het onderdeel is niet meer leverbaar.
