BMW LM-velg V-spaak 629 - 21'' for BMW 7 Series G12 LCI 730LdX (2020)
This BMW LM-velg V-spaak 629 - 21'' technical drawing provides a detailed breakdown of the assembly for the 7 Series G12 LCI 730LdX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| Nr. | Omschrijving | Toevoeging | Aantal | Van | Tot | Onderdeelnummer | Prijs | Notities | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Attentie: Vanwege de EU-accuverordening is een onderdeelbenaming voor RDC-sensoren of voor componenten met een vast gemonteerde accu wettelijk verplicht! Voor de klant moet bij de aankoop van dit product het bijbehorende document worden afgedrukt en overhandigd! Voor voertuigen met BMW LM-velg veelspaak 629 |
S2WRA=Ja |
||||||||
| 02 | Schijfwiel van lichtm. glanzend gedr. | 8,5JX21 ET:25 | 2 | 36116863112 | Shop at ECS Tuning | |||||
| alleen voor achteras | ||||||||||
| 02 | Schijfwiel van lichtm. glanzend gedr. | 10JX21 ET:41 | 2 | 36116863113 | Shop at ECS Tuning | |||||
| Banden van verschillend soort | ||||||||||
| 03 | Wielbout zwart | M14X1,25 | 20 | 36136890324 | Shop at ECS Tuning | |||||
| 04 | Naafdop met chroomrand | BMW | 4 | 36136850834 | Shop at ECS Tuning | |||||
| Voor voertuigen met Bandenspanningsweergave |
S2VBA=Nee |
|||||||||
| 05 | Rubberventiel | L=42,5MM | 4 | 36121116326 | $3.30 | Shop at ECS Tuning | ||||
| 06 | Ventiel-inzet | 4 | 36141095389 | $1.38 | Shop at ECS Tuning | |||||
| 07 | Ventieldop | 4 | 36121120779 | $0.60 | Shop at ECS Tuning | |||||
| Voor voertuigen met Bandenspanningsweergave |
S2VBA=Ja |
|||||||||
| 08 | Wielelek.moduul RDCi met schroefventiel | 433MHZ | 4 | 36106887147 | Shop at ECS Tuning | |||||
| Voor voertuigen met Bandenspanningsweergave en Radiofrequentie 315 MHz |
S2VBA=Ja S876A=Ja |
|||||||||
| 08 | Wielelek.moduul RDCi met schroefventiel | 315MHZ | 4 | 36106887146 | Shop at ECS Tuning | |||||
| Voor voertuigen met Bandenspanningsweergave |
S2VBA=Ja |
|||||||||
| 09 | Reparatieset schroefventiel RDCi | 4 | 36106874842 | Shop at ECS Tuning | ||||||
| 10 | Binnenventiel RDCi | 4 | 36146872777 | Shop at ECS Tuning | ||||||
| 11 | Ventieldopje RDCi | 4 | 36146872776 | Shop at ECS Tuning | ||||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series G12 LCI 730LdX BMW LM-velg V-spaak 629 - 21''?
- This technical diagram illustrates the BMW LM-velg V-spaak 629 - 21'' within the Wielen group for the 7 Series G12 LCI 730LdX produced during 2020. It provides a detailed exploded view of the components, identifying key parts such as the Schijfwiel van lichtm. glanzend gedr. (Part #36116863112).
- Which models use the hardware listed in this BMW LM-velg V-spaak 629 - 21''?
- The hardware and components featured in the BMW LM-velg V-spaak 629 - 21'' are specific to the 7 Series G12 LCI 730LdX produced during 2020. These technical specifications ensure that parts like the Schijfwiel van lichtm. glanzend gedr. (36116863112) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the BMW LM-velg V-spaak 629 - 21'' assembly?
- Each item in the BMW LM-velg V-spaak 629 - 21'' corresponds to the numbered list below the illustration. For the 7 Series G12 LCI 730LdX, you can identify the Schijfwiel van lichtm. glanzend gedr. by locating its position on the schematic, which then links to the official BMW part number 36116863112 for the Wielen section.
