Bekleding kofferdeksel boven for BMW 5 Series E39 530i (2001)
This Bekleding kofferdeksel boven technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2001.
| Nr. | Omschrijving | Toevoeging | Aantal | Van | Tot | Onderdeelnummer | Prijs | Notities | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Bekled.kofferdekdel li.zijdelings binnen | SCHWARZ | 1 | 51498216725 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel re.zijdelings binnen | SCHWARZ | 1 | 51498216726 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel li.zijdelings binnen | GRAU | 1 | 51498216727 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel re.zijdelings binnen | GRAU | 1 | 51498216728 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel li.zijdelings binnen | MARINEBLAU | 1 | 51498216729 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel re.zijdelings binnen | MARINEBLAU | 1 | 51498216730 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel li.zijdelings binnen | DUNKELGRUEN | 1 | 51498216731 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel re.zijdelings binnen | DUNKELGRUEN | 1 | 51498216732 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel li.zijdelings binnen | SANDBEIGE | 1 | 51498216733 | $13.57 | Shop at ECS Tuning | ||||
| 01 | Bekled.kofferdekdel re.zijdelings binnen | SANDBEIGE | 1 | 51498216734 | $13.57 | Shop at ECS Tuning | ||||
| 02 | Bekled.kofferdekdel li.zijdelings buiten | SCHWARZ | 1 | 51498194673 | $19.90 | Shop at ECS Tuning | ||||
| 02 | Bekled.kofferdekdel re.zijdelings binnen | SCHWARZ | 1 | 51498194674 | $19.90 | Shop at ECS Tuning | ||||
| 03 | Afdekking watergoot links | SCHWARZ | 1 | 51718220947 | $4.80 | Shop at ECS Tuning | ||||
| 03 | Afdekking watergoot rechts | SCHWARZ | 1 | 51718220948 | $4.80 | Shop at ECS Tuning | ||||
| 04 | Element | X | 07417203297 | $0.94 | Shop at ECS Tuning | |||||
| 05 | Bekled.kofferdeksel boven binnen | SCHWARZ | 1 | 51498215301 | $27.90 | Shop at ECS Tuning | ||||
| 05 | Bekled.kofferdeksel boven binnen | GRAU | 1 | 51498215302 | $27.90 | Shop at ECS Tuning | ||||
| 05 | Bekled.kofferdeksel boven binnen | MARINEBLAU | 1 | 51498215303 | $23.86 | Shop at ECS Tuning | ||||
| 05 | Bekled.kofferdeksel boven binnen | DUNKELGRUEN | 1 | 51498215304 | $27.90 | Shop at ECS Tuning | ||||
| 05 | Bekled.kofferdeksel boven binnen | SANDBEIGE | 1 | 51498215305 | $27.90 | Shop at ECS Tuning | ||||
| 06 | Bekled.kofferdeksel boven buiten | SCHWARZ | 1 | 51498190693 | $33.76 | Shop at ECS Tuning | ||||
| 07 | Bekleding achterruitraam boven | SCHWARZ | 1 | 51498194672 | $18.71 | Shop at ECS Tuning | ||||
| 08 | Afdekking watergoot | SCHWARZ | 1 | 51718220945 | $15.50 | Shop at ECS Tuning | ||||
| 09 | Bekled.kofferdeksel onder buiten | SCHWARZ | 1 | 51498204238 | $37.67 | Shop at ECS Tuning | ||||
| 10 | Klem bekleding kofferdeksel links | SCHWARZ | 3 | 51498217213 | $1.82 | Shop at ECS Tuning | ||||
| 10 | Klem bekleding kofferdeksel rechts | SCHWARZ | 3 | 51498217214 | $1.82 | Shop at ECS Tuning | ||||
| 11 | Aanslagrubber | 2 | 51248226064 | $2.32 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E39 530i Bekleding kofferdeksel boven?
- This technical diagram illustrates the Bekleding kofferdeksel boven within the Voertuig uitrusting group for the 5 Series E39 530i produced during 2001. It provides a detailed exploded view of the components, identifying key parts such as the Bekled.kofferdekdel li.zijdelings binnen (Part #51498216725).
- Which models use the hardware listed in this Bekleding kofferdeksel boven?
- The hardware and components featured in the Bekleding kofferdeksel boven are specific to the 5 Series E39 530i produced during 2001. These technical specifications ensure that parts like the Bekled.kofferdekdel li.zijdelings binnen (51498216725) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Bekleding kofferdeksel boven assembly?
- Each item in the Bekleding kofferdeksel boven corresponds to the numbered list below the illustration. For the 5 Series E39 530i, you can identify the Bekled.kofferdekdel li.zijdelings binnen by locating its position on the schematic, which then links to the official BMW part number 51498216725 for the Voertuig uitrusting section.
