Reparatie-omvangen airbag for BMW 7 Series G11 LCI 730dX (2020)
This Reparatie-omvangen airbag technical drawing provides a detailed breakdown of the assembly for the 7 Series G11 LCI 730dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| Nr. | Omschrijving | Toevoeging | Aantal | Van | Tot | Onderdeelnummer | Prijs | Notities | ||
|---|---|---|---|---|---|---|---|---|---|---|
| passend bij Knie-airbag bestuurder/passagierszijde |
||||||||||
| 01 | Reparatiekabel airbagsysteem | L= 2040MM | 2 | 61125A56386 | Shop at ECS Tuning | |||||
| Gordelspanner Gordelspanner bij de oprolautomaat voor en achter ITS hoofdairbag |
||||||||||
| 01 | Reparatiekabel airbagsysteem | L= 6120MM | 2 | 61125A56384 | Shop at ECS Tuning | |||||
| passend bij Future Brake System |
||||||||||
| 02 | Reparatiekabel airbagsysteem | L= 3034MM | 2 | 61125A56398 | Shop at ECS Tuning | |||||
| passend bij Adaptieve gordelkrachtbegrenzer |
||||||||||
| 02 | Reparatiekabel airbagsysteem | L= 4865MM | 2 | 61125A56396 | Shop at ECS Tuning | |||||
| passend bij Voetgangersbescherming voor |
||||||||||
| 03 | Reparatiekabel airbagsysteem | L= 3971MM | 2 | 61125A56391 | Shop at ECS Tuning | |||||
| passend bij Zijsensor links/rechts |
||||||||||
| 03 | Reparatiekabel airbagsysteem | L= 4218MM | 2 | 61125A56397 | Shop at ECS Tuning | |||||
| passend bij Upfrontsensor links en voetgangersbeveiliging voor midden |
||||||||||
| 03 | Reparatiekabel airbagsysteem | L= 3418MM | 1 | 61125A56395 | Shop at ECS Tuning | |||||
| passend bij Upfrontsensor rechts |
||||||||||
| 03 | Reparatiekabel airbagsysteem | L= 3562MM | 1 | 61125A56394 | Shop at ECS Tuning | |||||
| passend bij de passagiersairbag | ||||||||||
| 04 | Reparatiekabel airbagsysteem | L= 2519MM | 1 | 61125A56392 | Shop at ECS Tuning | |||||
| passend bij de passagiersairbag Met kortsluitveer, alleen passend bij passagiersairbag niveau 2 |
||||||||||
| 04 | Reparatiekabel airbagsysteem | L= 2000MM | 1 | 61126996654 | Shop at ECS Tuning | |||||
| 05 | Stopcontacthuis | 6 POL. | 1 | 61136982194 | Shop at ECS Tuning | |||||
| passend bij de bestuurdersairbag | ||||||||||
| 06 | Reparatiekabel airbagsysteem | L= 2519MM | 2 | 61125A56392 | Shop at ECS Tuning | |||||
| 07 | Stekker | 12 POL. | 1 | 61136954518 | Shop at ECS Tuning | |||||
| Bevat complete bedrading van de REMA gordels links en rechts |
||||||||||
| 08 | Reparatiekabel airbagsysteem REMA | 1 | 61119373814 | Shop at ECS Tuning | ||||||
| Omvat airbagkabel van de REMA gordel links/rechts zonder voeding |
||||||||||
| 08 | Reparatiekabel airbagsysteem | L= 4422MM | 2 | 61125A56381 | Shop at ECS Tuning | |||||
| passend bij Sensormat stoelbezettingsherkenning |
||||||||||
| 09 | Reparatiekabel airbagsysteem | L= 4239MM | 1 | 61125A56388 | Shop at ECS Tuning | |||||
| passend bij Upfrontsensor of voetgangersbescherming achter |
||||||||||
| 09 | Reparatiekabel airbagsysteem | L= 3562MM | 2 | 61125A56387 | Shop at ECS Tuning | |||||
| passend bij Verbinding van ACSM naar stekkerverbinding stoel voor airbag hoofdsteun, passagiersairbag of gordelspanner bij het stoelbevestigingspunt aan de portierzijde |
||||||||||
| 09 | Reparatiekabel airbagsysteem | L= 4239MM | 2 | 61125A56389 | Shop at ECS Tuning | |||||
| passend bij veiligheidsaccuklem 2 | ||||||||||
| 10 | Reparatiekabel airbagsysteem | L= 3497MM | 1 | 61125A56399 | Shop at ECS Tuning | |||||
