Klapa przednia/Elementy dod. for BMW 7 Series E38 740iL (1996)
This Klapa przednia/Elementy dod. technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 740iL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| Nr. | Opis | Uzupełnienie | Ilość | Od | Do | Numer części | Cena | Uwagi | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Pokrywa silnika stalowa | 1 | 11/1995 | 41618183124 | $1373.07 | Shop at ECS Tuning | ||||
| tylko w połączeniu z | ||||||||||
| -- | Siłownik pneumatyczny | 800N | 2 | 11/1995 | 51238150077 | $44.37 | Shop at ECS Tuning | |||
| 02 | Zaczep zamka | M10 | 2 | 51238164765 | $9.38 | Shop at ECS Tuning | ||||
| 03 | Element blokujący | 2 | 51238166682 | $2.00 | Shop at ECS Tuning | |||||
| 04 | Wkręt do blachy, czarny | ST4,2X13 | 2 | 07119901268 | $0.44 | Shop at ECS Tuning | ||||
| 04 | Wkręt | ST4,2X13 | 2 | 07119902526 | $0.20 | Shop at ECS Tuning | ||||
| 05 | Zaczep | 1 | 09/1998 | 51238164766 | $40.10 | Shop at ECS Tuning | ||||
| 06 | Śruba Torx z podkładką | M6X14 | 2 | 07149156085 | $0.56 | Shop at ECS Tuning | ||||
| 07 | Zamek pokrywy silnika część dolna lewa | 1 | 51238164763 | $43.73 | Shop at ECS Tuning | |||||
| 07 | Zamek pokrywy silnika część dolna prawa | 1 | 51238164764 | $43.73 | Shop at ECS Tuning | |||||
| 08 | Śruba Torx z podkładką | M6X12 | 2 | 07146985055 | $0.38 | Shop at ECS Tuning | ||||
| 09 | Płytka centrująca | 1 | 51238166681 | $8.07 | Shop at ECS Tuning | |||||
| 10 | Osłona zamka, lewa | 1 | 51238186901 | $2.13 | Shop at ECS Tuning | |||||
| 10 | Osłona zamka, prawa | 1 | 51238186902 | $2.13 | Shop at ECS Tuning | |||||
| 11 | Cięgno środkowe | 1 | 51238168163 | $28.29 | Shop at ECS Tuning | |||||
| 12 | Mechanizm otw. pokrywy silnika | 1 | 51238150080 | $24.11 | Shop at ECS Tuning | |||||
| 13 | Pierścień zaciskowy | 1 | 51238174461 | $0.89 | Shop at ECS Tuning | |||||
| 14 | Wkręt samogwintujący | ISA ST4.2X13 | 1 | 07147117570 | $0.25 | Shop at ECS Tuning | ||||
| 15 | Podkładka | 1.0MM | 2 | 41618172515 | $0.77 | Shop at ECS Tuning | ||||
| 16 | Dźwignia cięgna | 1 | 51238226621 | $3.18 | Shop at ECS Tuning | |||||
| 17 | Wkręt do tworz. szt. | TS 5X13 | 1 | 07146959892 | $0.30 | Shop at ECS Tuning | ||||
| 18 | Pokrywka | SCHWARZ | 1 | 51181823474 | $0.21 | Shop at ECS Tuning | ||||
| 19 | Osłona cięgna lewego | 1 | 51238186897 | $1.95 | Shop at ECS Tuning | |||||
| 19 | Osłona cięgna prawego | 1 | 51238186898 | $1.95 | Shop at ECS Tuning | |||||
| 20 | Listwa ochronna cięgna lewego | 1 | 51238186899 | $1.95 | Shop at ECS Tuning | |||||
| 20 | Listwa ochronna cięgna prawego | 1 | 51238186900 | $1.95 | Shop at ECS Tuning | |||||
| 21 | Zawias pokrywy silnika, lewy | 1 | 41618203271 | $110.37 | Shop at ECS Tuning | |||||
| 21 | Zawias pokrywy silnika, prawy | 1 | 41618203272 | $110.37 | +podst | Shop at ECS Tuning | ||||
| 22 | Folia lewa | 1 | 41618172565 | $5.27 | Shop at ECS Tuning | |||||
| 22 | Folia prawa | 1 | 41618172566 | $5.13 | Shop at ECS Tuning | |||||
| 23 | Siłownik pneumatyczny | 800N | 2 | 51238150077 | $44.37 | Shop at ECS Tuning | ||||
| 24 | Śruba torx z podkładką | 2 | 07149112449 | Shop at ECS Tuning | ||||||
| 25 | Śruba z podkładką | M6X16-Z3-2 | 2 | 07119915021 | $0.47 | Shop at ECS Tuning | ||||
| 26 | Śruba Torx z podkładką | ISA M8X15 | 2 | 41618226193 | $0.72 | Zakończono | Shop at ECS Tuning | |||
| 27 | Śruba Torx z podkładką | ISA M8X15 | 2 | 41618226193 | $0.72 | Zakończono | Shop at ECS Tuning | |||
| 28 | Trzpień kulisty | M8X13,5MM | 2 | 51247010221 | $2.03 | Shop at ECS Tuning | ||||
| 29 | Odbojnik z wyrzutnikiem | 34N | 2 | 51248187291 | $7.16 | Shop at ECS Tuning | ||||
| 30 | Uszcz. pokrywy silnika, przedn. lewa | 1 | 51718159943 | $64.81 | Shop at ECS Tuning | |||||
| 31 | Uszcz. pokrywy silnika, przedn. prawa | 1 | 51718159944 | $68.14 | Shop at ECS Tuning | |||||
| 32 | Odbojnik | 2 | 51238186700 | $1.92 | Shop at ECS Tuning | |||||
| 33 | Zaślepka | 19,6X5,8MM | 5 | 51718163996 | $0.40 | Shop at ECS Tuning | ||||
| 34 | Sworzeń uziemiający | M8X20/M6X11 | 1 | 07147202371 | Shop at ECS Tuning | |||||
Uwagi
- +podst = plus opłata podstawowa (możliwość zwrócenia starej części).
- Zakończono = część wycofana z produkcji.
