Lusterko zewnętrzne for BMW 7 Series E65 745i (2003)
This Lusterko zewnętrzne technical drawing provides a detailed breakdown of the assembly for the 7 Series E65 745i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.
| Nr. | Opis | Uzupełnienie | Ilość | Od | Do | Numer części | Cena | Uwagi | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Pasuje tylko do wersji "B" | ||||||||||
| 01 | Pokrywka gruntowana lewa | 1 | 12/2001 | 51167074235 | $48.89 | Shop at ECS Tuning | ||||
| 01 | Pokrywka gruntowana prawa | 1 | 12/2001 | 51167074236 | $48.89 | Shop at ECS Tuning | ||||
| 02 | Pierścień mocujący lewy | 1 | 51167002913 | $30.37 | Shop at ECS Tuning | |||||
| 02 | Pierścień mocujący prawy | 1 | 51167002914 | $30.37 | Shop at ECS Tuning | |||||
| 03 | Kpl. pokrywy | 1 | 51167046926 | $23.02 | Zakończono | Shop at ECS Tuning | ||||
| 04 | Siłownik lewy | 1 | 07/2005 | 67138362421 | $84.48 | Shop at ECS Tuning | ||||
| 04 | Siłownik prawy | 1 | 07/2005 | 67138362422 | $84.48 | Shop at ECS Tuning | ||||
| Dla samochodów z Fotel komfort z pamięcią lub Elektryczna regulacja foteli z pamięcią |
S456A=Tak S459A=Tak |
|||||||||
| 04 | Zest.napr. napędu lust. lewego z pam. | 1 | 07/2005 | 67138375457 | $188.25 | Shop at ECS Tuning | ||||
| 04 | Zest.napr. napędu lust. prawego z pam. | 1 | 07/2005 | 67138375458 | $188.25 | Shop at ECS Tuning | ||||
| 05 | Śruba z łbem walcowym | 6 | 07147196375 | $0.64 | Shop at ECS Tuning | |||||
| 06 | Zaczep | 8 | 51160016547 | $5.47 | Shop at ECS Tuning | |||||
Uwagi
- Zakończono = część wycofana z produkcji.
