Siedzenie z tyłu, podp. lędźwi for BMW 7 Series E65 745i (2003)
This Siedzenie z tyłu, podp. lędźwi technical drawing provides a detailed breakdown of the assembly for the 7 Series E65 745i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.
| Nr. | Opis | Uzupełnienie | Ilość | Od | Do | Numer części | Cena | Uwagi | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Poduszka lędźwiowa | 2 | 52107039191 | $37.83 | Shop at ECS Tuning | |||||
| Dla samochodów z Fotel komfort z pamięcią |
S456A=Tak |
|||||||||
| 02 | Pompa lędźwiowa | 2 | 52107039192 | $118.95 | Zakończono | Shop at ECS Tuning | ||||
| Dla samochodów z Fotel komfort siedz. tyln. reg. elektr. |
S460A=Tak |
|||||||||
| 02 | Pompa lędźwiowa | 2 | 52207070495 | $118.95 | Shop at ECS Tuning | |||||
| Dla samochodów z Fotel podst. elektr., regulowany |
=Tak |
|||||||||
| 02 | Pompa lędźwiowa | 2 | 52107037861 | $118.95 | Shop at ECS Tuning | |||||
| 03 | Zespół zaworowy | 2 | 52107039190 | $112.83 | Shop at ECS Tuning | |||||
| 04 | Kpl. przewodów elastycznych | 2 | 52209169270 | $60.35 | Shop at ECS Tuning | |||||
| 05 | Zestaw mocujący kable | 2 | 61117070505 | $15.73 | Shop at ECS Tuning | |||||
Uwagi
- Zakończono = część wycofana z produkcji.
