Worek na narty for BMW 7 Series E65 745i (2003)
This Worek na narty technical drawing provides a detailed breakdown of the assembly for the 7 Series E65 745i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.
| Nr. | Opis | Uzupełnienie | Ilość | Od | Do | Numer części | Cena | Uwagi | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Kaseta worka na narty | 1 | 72608240773 | $388.91 | Zakończono | Shop at ECS Tuning | ||||
| 02 | Panel podłokietnika | SCHWARZ | 1 | 72607051757 | $211.63 | Shop at ECS Tuning | ||||
| 02 | Panel podłokietnika | FLANELLGRAU | 1 | 72607051758 | $211.63 | Zakończono | Shop at ECS Tuning | |||
| 02 | Panel podłokietnika | BEIGE | 1 | 72607051759 | $211.63 | Zakończono | Shop at ECS Tuning | |||
| 02 | Panel podłokietnika | STEINGRUEN | 1 | 72607051760 | $211.63 | Zakończono | Shop at ECS Tuning | |||
| 02 | Panel podłokietnika | NATURBRAUN | 1 | 72607051761 | $211.63 | Zakończono | Shop at ECS Tuning | |||
| 02 | Panel podłokietnika | CREAMBEIGE | 1 | 72607051762 | $211.63 | Zakończono, +podst | Shop at ECS Tuning | |||
| 03 | Śruba z podkładką | M8X20-U1-8.8 | 1 | 07119904992 | $0.55 | Shop at ECS Tuning |
Uwagi
- Zakończono = część wycofana z produkcji.
- +podst = plus opłata podstawowa (możliwość zwrócenia starej części).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series E65 745i Worek na narty?
- This technical diagram illustrates the Worek na narty within the Wyposażenie i systemy bezpieczeństwa group for the 7 Series E65 745i produced during 2003. It provides a detailed exploded view of the components, identifying key parts such as the Kaseta worka na narty (Part #72608240773).
- Which models use the hardware listed in this Worek na narty?
- The hardware and components featured in the Worek na narty are specific to the 7 Series E65 745i produced during 2003. These technical specifications ensure that parts like the Kaseta worka na narty (72608240773) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Worek na narty assembly?
- Each item in the Worek na narty corresponds to the numbered list below the illustration. For the 7 Series E65 745i, you can identify the Kaseta worka na narty by locating its position on the schematic, which then links to the official BMW part number 72608240773 for the Wyposażenie i systemy bezpieczeństwa section.
