Montagem posterior Isofix for BMW 3 Series E46 330i (2005)
This Montagem posterior Isofix technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 330i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| Nr. | Descrição | Suplemento | Quantidade | De | Até | Número de Peça | Preço | Notas | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Para viaturas com Tecido Jacquard/cinza |
H9TT=Sim |
|||||||||
| 01 | Friso do separador traseiro | GRAU | 1 | 52207046800 | $157.36 | ENDED | Shop at ECS Tuning | |||
| Para viaturas com Tecido/pele "Maglia"/bege-claro 2 |
E9HC=Sim |
|||||||||
| 01 | Friso do separador traseiro | HELLBEIGE | 1 | 52207008471 | $265.72 | ENDED, +core | Shop at ECS Tuning | |||
| Para viaturas com Tecido Jacquard/anthrazit |
H9AT=Sim |
|||||||||
| 01 | Friso do separador traseiro | ANTHRAZIT | 1 | 52207046799 | $157.36 | ENDED | Shop at ECS Tuning | |||
| Para viaturas com Tecido/pele "Gran Turismo"/antracite |
E4AT=Sim |
|||||||||
| 01 | Friso do separador traseiro | ANTHRAZIT | 1 | 52207008464 | $265.72 | ENDED, +core | Shop at ECS Tuning | |||
| 02 | Suporte Isofix exterior | 1 | 72147006160 | $6.60 | Shop at ECS Tuning | |||||
| 02 | Suporte Isofix interior | 1 | 72147006162 | $6.60 | Shop at ECS Tuning | |||||
| 03 | Parafuso de cabeça oval | M10X26 | 4 | 07146962565 | $0.73 | Shop at ECS Tuning | ||||
Notas
- ENDED = a peça foi descontinuada
- +core = plus core charge (possibilidade de devolver a peça antiga)
