Tampa da mala for BMW MINI Clubman R55 Cooper (2006)
This Tampa da mala technical drawing provides a detailed breakdown of the assembly for the MINI Clubman R55 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2006.
| Nr. | Descrição | Suplemento | Quantidade | De | Até | Número de Peça | Preço | Notas | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vedação Splitdoor | 1 | 51762757822 | $87.46 | Shop at ECS Tuning | |||||
| 02 | Vedante do tejadilho atrás | 1 | 51767167238 | $22.00 | Shop at ECS Tuning | |||||
| 03 | Vedação Splitdoor lado esquerdo | 1 | 51767167241 | $59.64 | Shop at ECS Tuning | |||||
| 04 | Clip | 1 | 07130561277 | $0.21 | Shop at ECS Tuning | |||||
| 05 | Cobertura do caixilho do vidro esquerdo | 1 | 51497167449 | $28.12 | Shop at ECS Tuning | |||||
| 05 | Cobertura do caixilho do vidro direito | 1 | 51497167450 | $28.12 | Shop at ECS Tuning | |||||
| 06 | Óculo traseiro verde lado esquerdo | 1 | 51317167453 | $132.70 | Shop at ECS Tuning | |||||
| apenas em combinação com | ||||||||||
| -- | Aplicação friso embelezador Splitdoor | 1 | 51137167245 | $11.89 | Shop at ECS Tuning | |||||
| Para viaturas com Vidro protector do sol |
S420A=Sim |
|||||||||
| 06 | Óculo traseiro preto lado esquerdo | 1 | 51317167455 | Shop at ECS Tuning | ||||||
| apenas em combinação com | ||||||||||
| -- | Aplicação friso embelezador Splitdoor | 1 | 51137167245 | $11.89 | Shop at ECS Tuning | |||||
| 07 | Óculo traseiro verde lado direito | 1 | 51317167454 | $132.70 | Shop at ECS Tuning | |||||
| apenas em combinação com | ||||||||||
| -- | Aplicação friso embelezador Splitdoor | 1 | 51137167245 | $11.89 | Shop at ECS Tuning | |||||
| Para viaturas com Vidro protector do sol |
S420A=Sim |
|||||||||
| 07 | Óculo traseiro preto lado direito | 1 | 51317167456 | Shop at ECS Tuning | ||||||
| apenas em combinação com | ||||||||||
| -- | Aplicação friso embelezador Splitdoor | 1 | 51137167245 | $11.89 | Shop at ECS Tuning | |||||
| 08 | Aplicação friso embelezador Splitdoor | 2 | 51137167245 | $11.89 | Shop at ECS Tuning | |||||
| 09 | Friso embelezador Splitdoor esq. | 1 | 51132754061 | $26.34 | Shop at ECS Tuning | |||||
| 09 | Friso embelezador Splitdoor dir. | 1 | 51132754062 | $26.34 | Shop at ECS Tuning | |||||
| 10 | Suporte esquerdo | 1 | 51247167445 | $17.81 | Shop at ECS Tuning | |||||
| 10 | Suporte direito | 1 | 51247167446 | $17.81 | Shop at ECS Tuning | |||||
| 11 | Parafuso hexagonal com flange | M6X10-8.8-ZNS3 | 6 | 07119904128 | $0.53 | Shop at ECS Tuning | ||||
| 12 | Dobradiça Splitdoor com primário esq. | 1 | 41542757541 | $75.12 | Shop at ECS Tuning | |||||
| 12 | Dobradiça Splitdoor com primário drt. | 1 | 41542757542 | $75.12 | Shop at ECS Tuning | |||||
| 13 | Parafuso Torx com anilha | ISA M10X31 | 8 | 41517069659 | $25.80 | Shop at ECS Tuning | ||||
| 14 | Porca de flange | M8 | 6 | 51113414958 | $0.70 | Shop at ECS Tuning | ||||
| 15 | Disp.de paragem de borracha porta tras. | 1 | 51492756547 | $3.42 | Shop at ECS Tuning | |||||
| 16 | Parafuso de cabeça cilíndrica | 1 | 51122757174 | $0.59 | Shop at ECS Tuning | |||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Clubman R55 Cooper Tampa da mala?
- This technical diagram illustrates the Tampa da mala within the Carroçaria em bruto group for the MINI Clubman R55 Cooper produced during 2006. It provides a detailed exploded view of the components, identifying key parts such as the Vedação Splitdoor (Part #51762757822).
- Which models use the hardware listed in this Tampa da mala?
- The hardware and components featured in the Tampa da mala are specific to the MINI Clubman R55 Cooper produced during 2006. These technical specifications ensure that parts like the Vedação Splitdoor (51762757822) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Tampa da mala assembly?
- Each item in the Tampa da mala corresponds to the numbered list below the illustration. For the MINI Clubman R55 Cooper, you can identify the Vedação Splitdoor by locating its position on the schematic, which then links to the official BMW part number 51762757822 for the Carroçaria em bruto section.
