Luz de nevoeiro traseira for BMW MINI R56 One (2008)
This Luz de nevoeiro traseira technical drawing provides a detailed breakdown of the assembly for the MINI R56 One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2008.
| Nr. | Descrição | Suplemento | Quantidade | De | Até | Número de Peça | Preço | Notas | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Para viaturas com Conjunto aerodinâmico |
S7ARA=Não |
|||||||||
| 01 | Luz de nevoeiro traseira | 1 | 08/2010 | 63246946904 | $42.83 | Shop at ECS Tuning | ||||
| Para viaturas com Conjunto aerodinâmico |
S7ARA=Sim |
|||||||||
| 01 | Luz de nevoeiro traseira esquerda | 1 | 08/2010 | 63242751707 | $27.97 | Shop at ECS Tuning | ||||
| 01 | farolim de nevoeiro traseiro direito | 1 | 08/2010 | 63242751708 | $27.97 | Shop at ECS Tuning | ||||
| 02 | Suporte das lâmpadas | 1 | 08/2010 | 63247249647 | $9.32 | Shop at ECS Tuning | ||||
| 03 | Lâmpada Longlife | 12V 16W | 1 | 08/2010 | 63217160935 | $6.42 | Shop at ECS Tuning | |||
| 04 | Caixa contac.fêmea universal não cod. | 2 POL. | 1 | 08/2010 | 61138373332 | $2.70 | Shop at ECS Tuning | |||
| apenas em combinação com | ||||||||||
| -- | Contacto de tomada ELO-Power ELA c/ cabo | 0,2- 0,5 MM² SN | 4 | 08/2010 | 61130070581 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI R56 One Luz de nevoeiro traseira?
- This technical diagram illustrates the Luz de nevoeiro traseira within the Luzes group for the MINI R56 One produced during 2008. It provides a detailed exploded view of the components, identifying key parts such as the Luz de nevoeiro traseira (Part #63246946904).
- Which models use the hardware listed in this Luz de nevoeiro traseira?
- The hardware and components featured in the Luz de nevoeiro traseira are specific to the MINI R56 One produced during 2008. These technical specifications ensure that parts like the Luz de nevoeiro traseira (63246946904) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Luz de nevoeiro traseira assembly?
- Each item in the Luz de nevoeiro traseira corresponds to the numbered list below the illustration. For the MINI R56 One, you can identify the Luz de nevoeiro traseira by locating its position on the schematic, which then links to the official BMW part number 63246946904 for the Luzes section.
