3' E46 325xi Hydro steering-oil pipes

Hydro steering-oil pipes
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Intake manifold 1 09/2001 32411095526 $32.68
01 Intake manifold 1 09/2001 32416750155 $41.83
02 Hose clamp D=20,9-24,1 2 09/2001 32111131345 $2.12
02 Hose clamp 2 09/2001 32416751127 $1.12
03 Pressure hose assy 1 32416751242 $254.92 +core
04 Gasket ring D=7,65MM 1 64508390601 $1.93
05 Gasket ring A14X20-CUSN 2 32411093596 $0.31
06 Banjo bolt with check valve M14X1,5X27,4 1 32416781261 $10.02
07 Return pipe 1 32416796391
08 Gasket ring A16X22-CUSN 2 12/2005 32411093597 $0.27
08 Gasket ring A16X22 SFCU F22 2 32416773722 $0.65
09 Hollow bolt M16X28 1 02/2012 32416783887 $3.98 ENDED
09 Hollow bolt M16X28 1 32416852470
10 Cooling coil 1 17111436262 $57.27
11 radiator return line 1 32416796680
12 Hose clamp 1 32416751128 $0.98
13 Hex bolt with washer M6X12-U1-8.8 1 07119904517 $0.36
14 Cable tie 120MM 2 32411112282 $0.65
15 Self-locking hex nut M6-8-ZNNIV SI 1 07119905949 $0.24
16 Hex bolt with washer M6X14-U1-8.8 1 07119905525 $0.47
Notes
  • +core = plus core charge (possibility of a return of the old part)
  • ENDED = the part has been discontinued (no longer available).
