Oljehus / Detaljen for BMW 5 Series E60 525i (2007)
This Oljehus / Detaljen technical drawing provides a detailed breakdown of the assembly for the 5 Series E60 525i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| Nr. | Beskrivning | Tillägg | antal | Från | Upp till | Reservdelsnummer | Pris | Notering | ||
|---|---|---|---|---|---|---|---|---|---|---|
| För fordon med Aktiv styrning eller Dynamic Drive |
S217A=Nej S229A=Nej |
|||||||||
| 01 | Oljehus | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| 02 | Lock | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| 03 | Packning | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 04 | Skaft oljehus | 1 | 32416769287 | $23.59 | Shop at ECS Tuning | |||||
| 05 | Skaft oljehus | 1 | 32416760249 | $19.76 | Shop at ECS Tuning | |||||
| 06 | Gummilager | 3 | 02/2006 | 32416772178 | $2.93 | Shop at ECS Tuning | ||||
| 07 | Distanshylsa | ZNS3 | 2 | 07146977328 | $1.21 | Shop at ECS Tuning | ||||
| För fordon med Aktiv styrning eller Dynamic Drive har utgått |
S217A=Nej S229A=Nej |
|||||||||
| 08 | Underlagsplaata | 6,4X25X1,5 | 2 | 04/2008 | 07146977329 | $0.64 | Shop at ECS Tuning | |||
| För fordon med Aktiv styrning eller Dynamic Drive |
S217A=Nej S229A=Nej |
|||||||||
| 09 | Sexkantmutter | M6-8-ZNS3 | 2 | 04/2008 | 07119905128 | $0.44 | Shop at ECS Tuning | |||
| 09 | Sexkantmutter med plaata | M6 | 2 | 07147155614 | $0.91 | Shop at ECS Tuning | ||||
| 10 | Sexkantskruv med bricka | M6X16-U1-8.8 | 1 | 07119904524 | $0.25 | Shop at ECS Tuning | ||||
| 11 | Sexkantskruv | M5X14 | 2 | 07119904337 | $0.38 | Shop at ECS Tuning | ||||
| 12 | Haenvisningsskylt, oljehus-p. servostyrn | CHF 11.S | 1 | 71212122171 | $2.78 | Shop at ECS Tuning | ||||
