Delar SA 633 koffertrum for BMW 6 Series E64 650i (2007)
This Delar SA 633 koffertrum technical drawing provides a detailed breakdown of the assembly for the 6 Series E64 650i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| Nr. | Beskrivning | Tillägg | antal | Från | Upp till | Reservdelsnummer | Pris | Notering | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | För fordon med Styrning Combox |
S6VCA=Nej |
||||||||
| För fordon med Förberedelse mobiltelefon Business Beställning av en TCU (Telematics Control Unit) kan endast göras med uppgift om chassinummer. Vid leverans av utbytes-TCUn kodas chassinumret. Den kan inte kodas om. TCUn fungerar endast korrekt med passande kodning. Därför kan utbytes-TCUer inte beställas för lagerhållning! Kompletteringar och modifieringar till SA633 är inte möjliga! |
S633A=Ja |
|||||||||
| 01 | AT-Telematics Control Unit | GSM | 1 | 03/2008 | 84109193857 | Avslutad | Shop at ECS Tuning | |||
| 01 | RP REMAN Telematics Control Unit | GSM | 1 | 84109231093 | Avslutad | Shop at ECS Tuning | ||||
| För fordon med Förberedelse mobiltelefon Business och Navigationssystem Business och Navigationssystem Professional och Landsutförande Australien och Landsutförande England / Irland Beställning av en TCU (Telematics Control Unit) kan endast göras med uppgift om chassinummer. Vid leverans av utbytes-TCUn kodas chassinumret. Den kan inte kodas om. TCUn fungerar endast korrekt med passande kodning. Därför kan utbytes-TCUer inte beställas för lagerhållning! Kompletteringar och modifieringar till SA633 är inte möjliga! |
S633A=Ja S606A=Nej S609A=Nej L810A=Ja L812A=Nej |
|||||||||
| 01 | AT-Telematics Control Unit | GSM | 1 | 09/2007 | 84109187924 | Avslutad | Shop at ECS Tuning | |||
| 01 | Telematics Control Unit | GSM | 1 | 09/2007 | 84109149615 | Avslutad | Shop at ECS Tuning | |||
| För fordon med Förberedelse mobiltelefon Business och Navigationssystem Business och Navigationssystem Professional och Landsutförande Australien och Landsutförande England / Irland Beställning av en TCU (Telematics Control Unit) kan endast göras med uppgift om chassinummer. Vid leverans av utbytes-TCUn kodas chassinumret. Den kan inte kodas om. TCUn fungerar endast korrekt med passande kodning. Därför kan utbytes-TCUer inte beställas för lagerhållning! Kompletteringar och modifieringar till SA633 är inte möjliga! |
S633A=Ja S606A=Nej S609A=Nej L810A=Nej L812A=Ja |
|||||||||
| 01 | AT-Telematics Control Unit | GSM | 1 | 09/2007 | 84109187924 | Avslutad | Shop at ECS Tuning | |||
| 01 | Telematics Control Unit | GSM | 1 | 09/2007 | 84109149615 | Avslutad | Shop at ECS Tuning | |||
| 02 | Hållare styrdon hands free telefon | 1 | 03/2007 | 84109136584 | Avslutad | Shop at ECS Tuning | ||||
| 04 | Popnitbultar | M5X10,5 | 4 | 03/2005 | 07147116813 | $1.77 | Shop at ECS Tuning | |||
| 05 | Sexkantmutter | M5 | 4 | 03/2005 | 07129906048 | $0.73 | Shop at ECS Tuning | |||
| 06 | Antenn | BLUETOOTH | 1 | 03/2005 | 84506928461 | $24.30 | +stomme | Shop at ECS Tuning | ||
| 07 | Clip | 2 | 03/2005 | 84136940365 | $0.46 | Avslutad | Shop at ECS Tuning | |||
| 08 | Back-Up Antenn | 1 | 03/2005 | 65206935024 | $29.04 | Shop at ECS Tuning | ||||
| 09 | Tryckknopp | 2 | 03/2005 | 65206933753 | $0.77 | Shop at ECS Tuning | ||||
Notering
- Avslutad = delen tillverkas inte längre.
- +stomme = stomavgift tillkommer (eventuell retur av den gamla delen)
