Crankshaft with bearing shells for BMW 2500-3.3Li 3.0S (1974)
This Crankshaft with bearing shells technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0S. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1974.
| No. | รายละเอียด | Supp. | จำนวน | จาก | Up To | Part Number | ราคา | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | ตัวดูดซับแรงสั่นสะเทือน | 1 | 08/1968 | 02/1977 | 11231263878 | ENDED | Shop at ECS Tuning | |||
| เฉพาะใช้ร่วมกับ | ||||||||||
| -- | พูลเล่ย์ | X | 08/1968 | 02/1977 | 11511255356 | $342.97 | Shop at ECS Tuning | |||
| -- | สายพานพัดลม | 12,5X1055 | X | 08/1968 | 02/1977 | 11231711090 | $11.16 | Shop at ECS Tuning | ||
| 02 | พูลเล่ย์ | 124MM | 1 | 08/1968 | 02/1977 | 11211258274 | $60.68 | Shop at ECS Tuning | ||
| 03 | แหวนรอง | A8,4 | 8 | 08/1968 | 02/1977 | 24111690120 | $0.42 | Shop at ECS Tuning | ||
| 04 | โบลท์หัวหกเหลี่ยม | M8X16-10.9-PHR | 8 | 08/1968 | 02/1977 | 07119913612 | $0.62 | Shop at ECS Tuning | ||
| 05 | น็อตแบบปลอก | 1 | 11231308128 | $8.08 | Shop at ECS Tuning | |||||
| 06 | ชุดแหวนรองล็อคแบบสปริง เบอร์ 25 | B24 | 1 | 07509063160 | ENDED | Shop at ECS Tuning | ||||
| 07 | ดุม | 1 | 11231250126 | $71.15 | ENDED | Shop at ECS Tuning | ||||
| 08 | จานโซ่ | 1 | 11211252573 | $55.86 | Shop at ECS Tuning | |||||
| 09 | ลิ่มล็อคกันเลื่อน | 5X7,5 | 2 | 07119951485 | $0.47 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
