แผ่นป้าย / ตัวอักษร for BMW 5 Series E28 535i (1987)

This แผ่นป้าย / ตัวอักษร technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 535i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1987.

แผ่นป้าย / ตัวอักษร
No. รายละเอียด Supp. จำนวน  จาก   Up To  Part Number ราคา Notes
01 แผ่นเครื่องหมายติดฝากระโปรงหลัง 1 51141872969 $30.43 Shop at ECS Tuning
01 ป้ายเครื่องหมาย Ø 82MM 1 51148132375 $32.02 Shop at ECS Tuning
จำเป็นสำหรับการซ่อม
-- ปลอกยาง 2 51141807495 $0.68 Shop at ECS Tuning
02 ปลอกยาง X 51141902279 $0.62 Shop at ECS Tuning
07 แผ่นป้ายแบบติดกาว "535" 1 51141946164 $22.33 ENDED Shop at ECS Tuning
08 ป้ายติดกาว ด้านหลัง "I" 1 51141916137 $12.63 Shop at ECS Tuning
12 ป้ายติดกาว ด้านหลัง "IS" 1 51141945054 $25.21 Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).

See Also

Frequently Asked Questions

What assembly is shown in the BMW 5 Series E28 535i แผ่นป้าย / ตัวอักษร?
This technical diagram illustrates the แผ่นป้าย / ตัวอักษร within the อุปกรณ์ตัวถังรถ group for the 5 Series E28 535i produced during 1987. It provides a detailed exploded view of the components, identifying key parts such as the แผ่นเครื่องหมายติดฝากระโปรงหลัง (Part #51141872969).
Which models use the hardware listed in this แผ่นป้าย / ตัวอักษร?
The hardware and components featured in the แผ่นป้าย / ตัวอักษร are specific to the 5 Series E28 535i produced during 1987. These technical specifications ensure that parts like the แผ่นเครื่องหมายติดฝากระโปรงหลัง (51141872969) are correctly matched to the vehicle's structural and mechanical requirements.
How do I find specific parts within the แผ่นป้าย / ตัวอักษร assembly?
Each item in the แผ่นป้าย / ตัวอักษร corresponds to the numbered list below the illustration. For the 5 Series E28 535i, you can identify the แผ่นเครื่องหมายติดฝากระโปรงหลัง by locating its position on the schematic, which then links to the official BMW part number 51141872969 for the อุปกรณ์ตัวถังรถ section.
