支承桥 for BMW 3 Series E36 328i (1994)
This 支承桥 technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 328i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1994.
| 号码 | 详解 | 提供 | 数量 | 从 | 到 | 零件号码 | 价格 | 备注 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | 支承桥 | 1 | 82719404700 | $249.95 | 已经终止, +core | Shop at ECS Tuning | ||||
| 03 | 夹紧装置 | 4 | 82799405880 | $15.74 | 已经终止 | Shop at ECS Tuning | ||||
| 04 | 型材盖板 上部 | 2 | 82129413122 | $7.50 | 已经终止 | Shop at ECS Tuning | ||||
| 05 | 饰盖 | 4 | 82719402947 | $1.50 | 已经终止 | Shop at ECS Tuning | ||||
| 06 | 组件 扳手及螺栓 | 1 | 82799405049 | $29.00 | 已经终止 | Shop at ECS Tuning | ||||
| 07 | 钥匙 (代码) | 1 | 82799405012 | $11.75 | 已经终止 | Shop at ECS Tuning | ||||
| 08 | 模板 | 1 | 82799405881 | 已经终止 | Shop at ECS Tuning |
备注
- 已经终止 = 这个零件已经不再生产.
- +core = plus core charge (possibility of a return of the old part)
