支架 前部 for BMW 5 Series G30 LCI 520d (2020)
This 支架 前部 technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 LCI 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| 号码 | 详解 | 提供 | 数量 | 从 | 到 | 零件号码 | 价格 | 备注 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | 支架 保险杠 前部 | ECE | 1 | 51117385288 | Shop at ECS Tuning | |||||
| 用于车辆及 专业行车助手 和 自适应巡航控制系统+走走停停功能 |
S5AUA=否 S5DFA=否 |
|||||||||
| 02 | 架梁 保险杠 前部 下部 | 1 | 51117385290 | Shop at ECS Tuning | ||||||
| 用于车辆及 专业行车助手 和 自适应巡航控制系统+走走停停功能 |
S5AUA=是 S5DFA=是 |
|||||||||
| 02 | 架梁 保险杠 前部 下部 | ACC | 1 | 51117418224 | Shop at ECS Tuning | |||||
| 用于车辆及 专业行车助手 和 自适应巡航控制系统+走走停停功能 |
S5AUA=是 S5DFA=否 |
|||||||||
| 02 | 架梁 保险杠 前部 下部 | ACC | 1 | 51117418224 | Shop at ECS Tuning | |||||
| 用于车辆及 专业行车助手 和 自适应巡航控制系统+走走停停功能 |
S5AUA=否 S5DFA=是 |
|||||||||
| 02 | 架梁 保险杠 前部 下部 | ACC | 1 | 51117418224 | Shop at ECS Tuning | |||||
| 用于车辆及 M Technic 空气动力套件 |
S715A=是 |
|||||||||
| 03 | 减震器 上部 | M ECE | 1 | 51118098671 | Shop at ECS Tuning | |||||
| 用于车辆及 国家规格 中国 和 M Technic 空气动力套件 |
L8AAA=否 S715A=否 |
|||||||||
| 03 | 减震器 上部 | ECE | 1 | 51119498610 | Shop at ECS Tuning | |||||
| 用于车辆及 M Technic 空气动力套件 |
S715A=是 |
|||||||||
| 04 | 减震器 前部 下部 | M | 1 | 51118746307 | Shop at ECS Tuning | |||||
| 用于车辆及 国家规格 中国 和 M Technic 空气动力套件 |
L8AAA=是 S715A=否 |
|||||||||
| 04 | 减震器 前部 下部 | 1 | 51119463487 | Shop at ECS Tuning | ||||||
| 用于车辆及 国家规格 中国 和 M Technic 空气动力套件 |
L8AAA=否 S715A=否 |
|||||||||
| 04 | 减震器 前部 下部 | 1 | 51119463487 | Shop at ECS Tuning | ||||||
| 05 | 垂直连接件 左侧 | 1 | 51117357179 | Shop at ECS Tuning | ||||||
| 05 | 垂直连接件 右侧 | 1 | 51117357180 | Shop at ECS Tuning | ||||||
| 06 | 适配器 左 | 1 | 51117357215 | Shop at ECS Tuning | ||||||
| 06 | 适配器 右 | 1 | 51117357216 | Shop at ECS Tuning | ||||||
| 07 | 支架 | 2 | 51117357203 | Shop at ECS Tuning | ||||||
| 08 | 路沿石减震器 | 2 | 51117397396 | Shop at ECS Tuning | ||||||
| 11 | 盖板 横梁 | ECE | 1 | 51747359788 | Shop at ECS Tuning | |||||
| 12 | 六角螺栓 | M6X20-U2-ZNS3 | 2 | 07119904448 | $0.53 | Shop at ECS Tuning | ||||
| 13 | 平头螺栓 | M6X20-PCU2-10.9 | 8 | 07119908698 | Shop at ECS Tuning | |||||
| 14 | 盲铆钉 | 2 | 07147234212 | Shop at ECS Tuning | ||||||
| 15 | ISA 螺栓 | M8X100-U1-8.8 | 2 | 07149908709 | Shop at ECS Tuning | |||||
| 16 | 星形螺栓 带平垫圈 | ISA M8X25 | 2 | 07147301867 | Shop at ECS Tuning | |||||
| 17 | 六角螺栓 | M12X1,5 10.9ZNS | 6 | 07147422947 | Shop at ECS Tuning | |||||
| 18 | 星形螺栓 带平垫圈 | ISA M8X25 | 8 | 07147301867 | Shop at ECS Tuning | |||||
